Prefab House Non Asbestos Calcium Silicate Board With ASTMC
Description:
Calcium silicate board is an asbestos-free thermal insulation product that can withstand continuous operating temperature from 650C up to 1100C. It is light weight, low thermal conductivity, high strength, easy to install, reliable and durable. There are 3 grades available namely 650 &1000 & 1100 which are commonly used as furnace backup insulation in steel, petrochemical, ceramic, cement & glass industry or fire protection in building construction. It not only provides energy saving, also increases production efficiency and gives personnel protection in industrial safety aspect. And in the housing construction Calcium Silicate Board is also used as the ceiling, fireproof and heat insulation materials of wall and sound absorption materials of decoration.
Product Feature
Durability and long service life
Excellent heat and sound insulation
High strength with 9000 tons pressing machine
Easy processing and installation,save cost and time
Excellent fire-proof performance,A1 class incombustible
High temperature,high pressure autoclaved for 24 hours
Partition board,Interior/exterior wall panel (office,emporium,hotel,hospital,sxhool,station and so on),Suspended ceiling
Physical/ Mechanical Properties: | ||
Size | Standard Size | Size:1220*2440*6/8/9/10/12/15/18mm |
Appearance | Surface | Surface:Un-Sanded/Sanded/Polished; |
Edge | Square/Recessed | |
Density | 1.25-1.35g/cm3 | |
Moisture Movement | <0.25% | |
Moisture Content | <10% | |
Physical Properties | Thermal Conductivity | ≤0.2 w/(m •k) |
Non-combustibility | GB 8624-2006 Grade A1 Grade | |
Application | Interior Ceiling and patition wall of all kinds of civil building, renovation of old building,ceiliing and baseboard in the clean room of medical buidling,surgery room,clean room for medical production,research laboratory etc.... | |
Executive Standard | JC/T 564.1-2008 Fiber reinforeced calcium silicate board,first part: calcium silicate board with non-asbestos | |
Remark: 1. The above mentioned just prescribe the range. The actual
specification can be selected according to construction module
among the specified range 2. Other specfication can be produced according to contract upon request. |
Flexural Strength | ||||
Strength Grade | Density 0.8g/cm3 | Density 1.1g/cm3 | Density 1.3g/cm3 | Aspect intensity ratio |
II | 5 | 6 | 8 | |
III | 6 | 8 | 10 | 58% |
IV | 8 | 10 | 12 | |
V | 10 | 14 | 18 |
![]() |
